HTP Series Powder Lifting Bin Mixer | Dry Powder Mixer Blender

Description

Features:

1. Intelligent PLC control, graphical interface

2. The inside of the hopper is smooth and has no dead angle. The mixture is sealed to prevent dust from entering and cross-contamination.

3. Configure anti-misoperation discharge butterfly valve

4. Easy to operate, maintain and clean

5. Mobile hopper is convenient for transferring materials, convenient for loading and unloading

6. Mixing time and mixing speed can be adjusted through the touch screen to ensure good mixing effect, automatic positioning of the system, automatic fault prompts and alarms.

Finished Product Display

Specification

Model	Mixing speed rpm	Hopper volume L	Maximum load volume L	Maximum load capacity Kg	Main power Kw	Weight Kg
HTP-50	3-20	50	40	25	3.7	600
HTP-100	3-20	100	80	50	3.7	700
HTP-200	3-20	200	160	100	4.4	800
HTP-300	3-20	300	240	150	5.2	900
HTP-400	3-20	400	320	200	5.2	1000
HTP-500	3-15	500	400	250	5.2	1200
HTP-600	3-15	600	480	300	5.2	1300
HTP-800	3-15	800	640	400	7	1600
HTP-1000	3-10	1000	800	500	7	2000
HTP-1200	3-8	1200	960	550	7	2200

FAQ - Have any questions?

What is the capacity range of the HTP Series Powder Lifting Bin Mixer?

The capacity of the HTP Series typically ranges from 40L to 960L, accommodating varying batch sizes.

What types of materials can be mixed using the HTP Series Lifting Bin Mixer?

This mixer is suitable for blending dry powders or granules used in pharmaceutical, food, or chemical industries.

How efficient is the mixing process with the HTP Series Powder Lifting Bin Mixer?

The HTP Series Mixer ensures efficient blending due to its lifting bin design, promoting thorough mixing and homogeneity.

Is the mixing process uniform and consistent with the HTP Series Mixer?

Yes, the lifting bin design ensures uniform mixing, maintaining consistency across batches.

Can the HTP Series Mixer handle delicate or fragile materials during mixing?

Yes, it's designed to handle delicate materials gently to prevent breakage or damage during the blending process.

What safety features are integrated into the HTP Series Powder Lifting Bin Mixer?

Safety features may include emergency stop buttons, safety guards, and mechanisms to prevent accidents during operation.

How is the cleaning process for the HTP Series Mixer?

The machine is designed for easy cleaning and maintenance, with removable parts and accessible surfaces for efficient cleaning.

Can the mixing intensity or speed be adjusted or customized?

Yes, some models may allow for adjustable mixing intensity or speed based on specific material requirements.

Is the HTP Series Lifting Bin Mixer suitable for handling materials with varying densities?

Yes, it's designed to handle materials with different densities, ensuring thorough blending despite varying properties.

What technical support is provided with the purchase of the HTP Series Powder Lifting Bin Mixer?

Comprehensive technical support, including setup guidance, training, and ongoing assistance, is typically offered to ensure optimal use of the equipment.

Investment Return Analysis: Growth Prospects for HTP Series Powder Lifting Bin Mixer

Market Potential:

Industry Demand: The HTP Series Powder Lifting Bin Mixer serves industries like pharmaceuticals, food, and chemicals, meeting the rising demand for efficient blending of dry powders and granules.

Expanding Industries: As these industries expand globally, the need for advanced blending equipment intensifies, consequently increasing the demand for the HTP Series Mixer.

Competitive Advantage:

Lifting Bin Design: The mixer's lifting bin structure ensures thorough and homogeneous blending, offering an advantage over conventional mixers.

Versatility: Its capability to blend various dry materials efficiently caters to diverse industry requirements, enhancing its market competitiveness.

Technological Advancements:

Innovation Potential: Potential technological upgrades could further improve its efficiency and adaptability, ensuring continued competitiveness.

R&D Investment: Continued research and development efforts may lead to improved functionalities, meeting evolving industry needs.

Cost Efficiency:

Operational Savings: Efficient blending reduces production time and material wastage, contributing to cost savings and heightened productivity.

Resource Optimization: Its ability to handle various materials optimizes resource utilization, aligning with sustainable manufacturing practices.

Conclusion:

Investing in the HTP Series Powder Lifting Bin Mixer presents promising returns aligned with the escalating demand for efficient and versatile blending solutions across multiple industries. Its competitive advantages in efficiency, versatility, and potential technological advancements position it favorably for substantial market uptake.
