ZFG Series Conical Screw Vacuum Dryer

Product Description

ZFG Series Dryer is engineered for high-performance drying of sensitive, hazardous, or high-value materials across industries such as pharmaceuticals, chemicals, and food processing. Its closed, indirect heating system ensures a contamination-free environment while protecting thermally unstable or reactive substances from degradation. The innovative conical design and heated central shaft synergize to deliver rapid, uniform drying with minimal residue, supported by adjustable mixing speeds for tailored material handling.

Safety and compliance are prioritized through explosion-proof motors and robust shaft seals, making it ideal for hazardous environments. The modular vacuum system enhances sustainability by recycling solvents, while the integrated heated dust collector maintains operational cleanliness. With user-friendly accessories and a focus on gentle processing, the ZFG Series guarantees high product quality, operational efficiency, and adherence to stringent industrial standards.

Specification

TYPE		ZFG600	ZFG700	ZFG1000	ZFG1200A	ZFG1200B	ZFG1400A	ZFG1400B	ZFG1500	ZFG1800
Total volume	L	100	150	450	700	900	1200	1500	1800	2800
Power	KW	1.5	1.5	3	4	4	5.5	7.5	7.5	15
Max. rotation speed	rpm	63	66	67	64	64	65	65	42	55
Outline size	mm	700×700×1600	850×850×1900	1200×1200×2525	1300×1300×2850	1300×1300×3000	1640×1640×3200	1640×1640×3200	1740×1740×3400	2280×2280×4000
Installation dimensions	mm	φ640	φ750	φ1100	φ1200	φ1200	φ1500	φ1500	φ1600	φ2100
Net weight	kg	500	600	900	1300	1500	1900	2200	2500	3600

FAQ - Have any questions?

What are the main application areas of the ZFG Series Conical Screw Vacuum Dryer?

ZFG Series Conical Screw Vacuum Dryer is primarily used in the pharmaceutical, chemical, and food industries, especially for drying heat-sensitive, easily oxidized, volatile, and explosive materials.

What is the drying principle of this equipment?

ZFG Series equipment dries materials by stirring them with a conical screw agitator in a vacuum environment, causing moisture or solvents in the materials to evaporate rapidly under negative pressure.

What heating options are available for the equipment?

Depending on customer needs, the ZFG Series equipment can be equipped with steam heating, thermal oil heating, or electric heating.

What is the processing capacity of the equipment?

The processing capacity depends on the model and specifications of the equipment and needs to be customized based on material characteristics and customer requirements.

Is the equipment easy to operate and maintain?

ZFG Series equipment is designed reasonably with a user-friendly operation interface that is easy to learn and master. Additionally, the equipment is simple to maintain and clean.

Is the equipment material corrosion-resistant?

Yes, the main components of the ZFG Series equipment are made of corrosion-resistant materials such as stainless steel to ensure stable operation in harsh environments.

What is the energy consumption of the equipment?

ZFG Series equipment adopts advanced energy-saving technology, resulting in lower energy consumption and more economic operating costs compared to traditional drying equipment.

What is the noise level of the equipment?

The equipment operates with low noise levels, complying with relevant environmental standards and not causing interference to the working environment.

What is the delivery lead time for the equipment?

The delivery lead time depends on the equipment model, specifications, and customer requirements. Generally, standard equipment has a shorter delivery lead time, while customized equipment may have a slightly longer lead time.

What kind of after-sales service do you provide for the equipment?

We offer comprehensive after-sales service, including equipment installation and commissioning, operation training, maintenance, and repairs. Additionally, we have a 24/7 customer service hotline to promptly address any issues encountered by customers during use.
